PVC coated gabion mesh is engineered with a specialized coating process that significantly enhances its corrosion resistance. This product not only extends the structural lifespan but also plays a crucial role in river training, slope stabilization, and ecological restoration projects. The following sections provide an in-depth analysis of its protective features and versatile applications.
The PVC coating serves as a strong external shield for the metal wire mesh, greatly reducing exposure to air, moisture, oxygen, and other corrosive substances. This dual-protection system—heavy zinc coating combined with PVC encapsulation—is especially suited for environments with high humidity, salt content, or pollution levels. It effectively addresses the limitations of traditional wire mesh, such as rusting and premature aging. Even under prolonged immersion or extreme weather conditions, the pvc coated gabion mesh retains its structural integrity.
PVC material exhibits excellent resistance to UV radiation and extreme weather conditions. In hot, cold, or sun-exposed environments, the coating resists aging, cracking, and peeling. Its durability against long-term wind, sun, and precipitation ensures that the pvc coated gabion mesh performs consistently in outdoor applications. This level of weatherability is critical for structures that remain exposed year-round.
PVC not only resists chemical corrosion from acids, alkalis, and salts, but also offers biological resistance. Its smooth surface discourages the attachment and growth of algae, aquatic plants, and microorganisms, reducing structural damage from biological fouling. Whether in coastal zones, industrial sites, or wastewater treatment areas, the pvc coated gabion mesh maintains excellent performance and ensures long-term stability and safety.
Thanks to its advanced anti-corrosion properties, the pvc coated gabion mesh can last over 15 to 20 years with proper installation and maintenance, significantly reducing repair and replacement costs. Common applications include:
Riverbanks and Reservoirs: Protects against erosion and prevents embankment collapse.
Ecological Restoration & Soil Conservation: Promotes vegetation growth and minimizes soil loss.
Slope Reinforcement & Protection: Stabilizes embankments and steep terrain.
Coastal Engineering: Withstands saltwater corrosion and wave impact.
Environmental Landscaping: Combines structural safety with visual appeal to enhance landscapes.
| Item | Details |
|---|---|
| Product Name | PVC Coated Gabion Mesh |
| Also Known As | PVC Coated Gabion Baskets, PVC Coated Gabion Wire Mesh |
| Manufacturer | Shenzhou ADS Wire Fencing Co., Ltd. |
| Material | High-tensile galvanized steel wire (low-carbon), coated with PVC |
| Structure | Double-twisted hexagonal woven wire mesh, forming baskets or boxes |
| Wire Specifications | Mesh wire: 2.0/3.0 mm (zinc > 215g/m²) or 2.7/3.7 mm (zinc > 245g/m²); thicker edge wires |
| Mesh Size | 8×10 cm, 6×8 cm (customizable) |
| Standard Sizes | 2×1×1 m, 3×1×1 m, 4×1×1 m (customizable) |
| PVC Coating Features | Thickness: approx. 0.4–0.5 mm; Color: green, gray, etc. (customizable); UV-, acid-, and abrasion-resistant |
| Corrosion Resistance | Base layer of heavy zinc for rust protection; PVC coating enhances resistance to humidity, saltwater, and chemical exposure |
| Service Life | Over 15 years with correct installation and maintenance |
| Permeability | Allows water flow to maintain hydraulic balance and prevent pressure buildup |
| Flexibility | Adapts to terrain variations; ideal for irregular or shifting surfaces |
| Installation Method | Simple assembly; panels interlocked via twisted mesh; no special skills or tools required |
| Key Advantages | Outstanding corrosion resistance and durability; easy to install and maintain; eco-friendly and vegetation-compatible; adaptable to various environments |
| Typical Applications | Retaining walls, erosion control, river channel lining, landscaping, flood prevention, slope protection |
| Environmental Suitability | Ideal for high-humidity, saltwater, or chemically exposed areas—especially rivers and coastal projects |
| Eco-Friendliness | Permeable design supports plant growth and integrates naturally into the environment |
| Customization Options | Mesh size, wire diameter, panel dimensions, and coating color customizable to project requirements |
| Compliance Standards | Conforms to ASTM A975-97, EN 10223-3, and other international standards |
