Macmat-Steel Reinforced 3D Geomat

Macmat-Steel Reinforced 3D Geomat

Andesen is a leading 3D geomat company, providing reinforced geomat retaining wall with composite materials that combine the benefits of a 3D mat structure with the reinforcement properties of either a double twisted steel mesh or a synthetic geogrid. This combination results in a geomat erosion control that offers both erosion control capabilities and structural reinforcement.


The 3D geomat structure of reinforced geomats provides effective erosion control by stabilizing soil, preventing surface erosion, and promoting vegetation growth. The geomat retaining wall structure consists of interconnected fibers or filaments that create a matrix, which helps retain soil particles and dissipate the energy of flowing water. Learn more about from -SHENZHOU ANDESEN WIRE FENCING CO., LIMITED. is a China leading 3D geomat company and supplier, providing erosion control geomats for driveways. Contact us to learn about the Geomat price now!

Contact Andesen

Features of Macmat-Steel Reinforced 3D Geomat

Steel reinforcement erosion control geomat plays a crucial role in providing stability and enhancing surface protection on very steep slopes where the soil cover is limited. In such cases, the use of steel reinforcement within a geomat can significantly improve the performance and effectiveness of erosion control measures.



Specification of Macmat-Steel Reinforced 3D Geomat

Macmat-Steel Reinforced Geomat

Item 1

Hole Size

(mm)

Wire Diameter

(mm)

Edge Wire Diameter

(mm)

Material

Life period

(year)

Remark

Hexagonal wire netting

60x80

2.0-3.0

2.7-3.4

Alu-zinc coated wire

+20

Service year varies according to environment

80x100

Galvanized steel wire

0.5-5

Item 2

Melting Point

(℃)

Void index

(%)

Polymer

Density

(kg/m3)

UV Resistance

Geo mat

150

≥90

polypropylene

900

Stable

Item 3

Geo mat color

Length

m/roll

Width

m

Area

m2

Macmat-steel reinforced geomat

Black,green

25

2

50



Diagram of Macmat-Steel Reinforced 3D Geomat

Diagram of Macmat-Steel Reinforced 3D Geomats



Application of Macmat-Steel Reinforced 3D Geomats

  • Coastal Protection, Marine Structures & Pipeline Protection

  • Environment, Dewatering & Landfills

  • Erosion Control

  • Hydraulic Works

  • Landscape & Architecture

  • Rockfall Protection & Snow Barriers


Highlight of Macmat-Steel Reinforced 3D Geomat

Highlight of Macmat-Steel Reinforced 3D Geomat

1. Structural Stability
2. Soil Retention
3. Vegetation Support
4. Longevity and Durability
1
Structural Stability

Steel reinforcement plays a crucial role in providing stability and enhancing surface protection on very steep slopes where the soil cover is limited. In such cases, the use of steel reinforcement within a geomat can significantly improve the performance and effectiveness of erosion control measures. As a leading 3d geomat factory, SHENZHOU ANDESEN WIRE FENCING CO., LIMITED. provides useful erosion control geomat.

2
Soil Retention

The double twisted steel mesh within the geomat acts as a containment system, preventing soil particles from being washed away by water flow. It retains soil within the mat structure, preventing surface erosion, and preserving the integrity of the slope. This is especially important when the soil cover is limited, as the reinforcement helps maintain a protective layer of soil on the slope surface.

3
Vegetation Support

The steel reinforcement within the geomat also provides support for vegetation growth. The mesh structure allows plant roots to anchor into the reinforcement, promoting vegetation establishment and growth. This further enhances surface protection by providing additional stability and reducing the impact of water flow on the slope.

4
Longevity and Durability

Steel reinforcement is highly durable and resistant to environmental factors, making it suitable for long-term slope stabilization. It can withstand harsh conditions, such as high water flow rates, freeze-thaw cycles, and UV exposure, ensuring the longevity and effectiveness of the erosion control measures.

Macmat-Steel Reinforced 3D Geomat Production Process
