| PVC Coated Gabion Box | ||||||
| Regular Size | Mesh Size | |||||
| Length | Width | Height | 8cm*10cm | 6cm*8cm | ||
| (m) | (m) | (m) | Mesh Wire | Zinc Weight | Mesh Wire | Zinc Weight |
| 2 | 1 | 1 | 2.7/3.7mm | ﹥245g/m² | 2.0/3.0mm | ﹥215g/m² |
| 3 | 1 | 1 | Edge Wire | Zinc Weight | Edge Wire | Zinc Weight |
| 4 | 1 | 1 | 3.4/4.4mm | ﹥265g/m² | 2.7/3.7mm | ﹥245g/m² |
| 6 | 1 | 1 | Lacing Wire 2.2/3.2mm | Lacing Wire 2.0/3.0mm | ||
| Remark: Alternative Mesh Size: 80*120mm,100*120mm,100*150mm,120*150mm Customer's label can be printed on the pvc coated wire | ||||||
| Galvanized Gabion Box | ||||||
| Regular Size | Mesh Size | |||||
| Length | Width | Height | 8cm*10cm | 6cm*8cm | ||
| (m) | (m) | (m) | Mesh Wire | Zinc Weight | Mesh Wire | Zinc Weight |
| 2 | 1 | 1 | 2.7mm | ﹥245g/m² | 2.0mm | ﹥215g/m² |
| 3 | 1 | 1 | Edge Wire | Zinc Weight | Edge Wire | Zinc Weight |
| 4 | 1 | 1 | 3.4mm | ﹥265g/m² | 2.7mm | ﹥245g/m² |
| 6 | 1 | 1 | Lacing Wire 2.2mm | Lacing Wire 2.0mm | ||
| Remark: Alternative Mesh Size: 80*120mm,100*120mm,100*150mm,120*150mm Customer's label can be printed on the pvc coated wire | ||||||
| Welded Gabion Box | |||||
| Regular Size | Number of Diaphragms | Wire Diameter | Hole Size | ||
| Length | Width | Height | PCS | mm | mm |
| (m) | (m) | (m) | |||
| 1 | 1 | 0.5 | 0 | 2-5 | 50x50 75x75 50x100 100x100 |
| 1 | 1 | 1 | 0 | ||
| 1.5 | 1 | 0.5 | 0 | ||
| 1.5 | 1 | 1 | 0 | ||
| 2 | 1 | 0.5 | 1 | ||
| 2 | 1 | 1 | 1 | ||
| 3 | 1 | 0.5 | 2 | ||
| 3 | 1 | 1 | 2 | ||
| 4 | 1 | 0.5 | 3 | ||
| 4 | 1 | 1 | 3 | ||
| Remark: Customized specification can be done | |||||
